Full automatic cup mask making machine(NK-LRW1901)

Full automatic cup mask making machine(NK-LRW1901)

DG SOUTH NEKON CO., LTD was founded in 1997, located in the beautiful Shipai Town in Dongguan City, Guangdong Province. South Nekon is a high technical private enterprise owing independent import-export operation rights. Since the establishment, the company has been devoted to optimization and integration of developing, producing, selling, and applicating of technology of ultrasonic machinery (Ultrasonic rhinestone fixing machine,face mask making machine, ultrasonic ribbon cutting machine, ultrasonic lace sewing machine, ultrasonic plastic welding machines, high frequency fusing machine). more than 10 years of experience in automation technology,South Nekon can provide full automation non-standard fabric sewing and cutting equipment according to the specail request. The company established its own brand “nekon”, and the registered trademark is "nekon", we have more than 200 workers(more than 80 technicians and managers with college education). And the head company has an area of more than 10,000 ㎡with branch company around the main cities of China such as Wenzhou, Kunshan, Ningbo, Fujian, Zhongshan, Guangzhou, Foshan etc.
 Model  NK-LRW1901
 Driving Motion  Servo motor & synchronous belt
 Electric Control  Mitsubishi PLC
 Control Panel  Human-computer interface(Touch screen)
Process Loading-Nose clip melting-Earloop weling-Breather valve hole punching-breather valve welding-Collect
 Supply Voltage  380VAC,50/60HZ,1Phase
 Power 4.5KW
 Air Pressure  0.5-0.6Mpa
 Ultrasonic Frequency  20KHZ
 Capacity  15-20PCS/MIN
 Mask Shape  Cup type
 Material Application  Terylene ear-loop
 Dimensions  3800*1860*1800MM
Net Weight 1150Kg
The above parameters and configuration is for reference only, specific configuration by mutual agreement shall prevail
